Titan HD2P-11000ACX 11,000lb 2 Post Car Lift

HD2P-11000ACX 2-Post Lift by Titan

The Titan HD2P-11000ACX 2-Post Lift is the perfect solution for those who need a higher lifting capacity but have limited ceiling height. With an 11,000 lb. lifting capacity, this asymmetric clear-floor lift is designed for heavy-duty performance while maintaining a compact footprint. Its adjustable two-piece columns allow for an overall height of either 142 inches or 146 inches, making it compatible with standard 9K clear-floor lift spaces. This feature is ideal for shops with height restrictions, ensuring versatility without sacrificing lifting power. The padded cut-off bar with automatic electric override provides an added layer of safety, while the single-point lock release simplifies operation. The stackable truck adapters make it easy to accommodate a variety of vehicles, from cars to larger trucks, providing enhanced flexibility for professional and home garages alike.

2-Post Lift HD2P-11000ACX Specifications

• Overall Height: 142" or 146"
• Overall Width: 137.375"
• Width Between Posts: 110.75"
• Drive-Thru Width: 98.5"
• Min Pad Height: 4.75"
• Max Pad Height: 82"
• Lifting Speed: 50 seconds
• Lifting Capacity: 11,000 lbs
• Concrete Spec Min: 6" @ 3,000 PSI
• Power Unit: 220V-1PH-60HZ-20AMP
• Shipping Dimensions: 115" (L) x 20" (W) x 48" (H)
• Shipping Weight: 2,200 lbs


HD2P-11000ACX 2-Post Lift Special Features

• 11,000 lb. lifting capacity for heavy-duty applications
• Adjustable two-piece columns (142" or 146" height) for versatility
• Padded cut-off bar with automatic electric override for safety
• Single-point lock release for easy operation
• Stackable truck adapters for accommodating different vehicle heights
• Durable powder-coated finish for long-lasting performance
• Free mounting hardware for easy setup
  • 1-year electric/hydraulic warranty and 5-year structural warranty

HD2P-11000ACX Manual

  Titan HD2P-11000ACX Manual

  Titan HD2P-11000ACX Spec Sheet
